TODPA SOUND PROOF CRUSHER
1.Fully airtight silent designed, noise below 80db without 1 meter away from the machine,avoids powder contamination.
2.Elegant designed with options available.
3.Installed with heat transmitting system, expel heat generated from the electric motor, protection and safety without any problem for long hours operation
4.Stainless steel material storage tank easy for cleaning & re-move, stainless steel suction spout available upon require
5.Installed with safety protection system , appliances meeting the European safety standard.
6.Installed with electrical phase controller & power isolator, safety operation and simple maintenance.
7.Installed with power isolator, safety operation and simple maintenance
8.Movable stainless steel multi-positional tray feed & closes for complete soundproof operation
| Features: | ||||||||
| Model | Crushing chamber | Crushing capability | Stationary cutter | Rotary cutters | Power | Dimensions | Weight | |
| (mm) | (kg/h) | (pcs) | (pcs) | Kw | HP | (L×W×H mm) | (kg) | |
| PC-265SF | 265*220 | 100-150 | 2 | 15 | 4 | 5 | 1250*720*1300 | 360 |
| PC-300SF | 315*230 | 120-200 | 2 | 9 | 5.5 | 7.5 | 1150*760*1280 | 380 |
| PC -400SF | 410*270 | 200-250 | 2 | 12 | 7.5 | 10 | 1200*850*1380 | 450 |
| PC -500SF | 500*300 | 300-350 | 2 | 15 | 11 | 15 | 1400*980*1580 | 800 |
| PC -600SF | 600*320 | 350-450 | 2 | 6 | 15 | 20 | 1600*1140*1850 | 1100 |
| PC -700SF | 720*400 | 400-550 | 2 | 6 | 22 | 30 | 2000*1350*2200 | 1500 |
| PC -720SF | 720*500 | 450-600 | 2 | 6 | 30 | 40 | 2000*1500*2300 | 1600 |
| PC -800SF | 805*450 | 500-650 | 4 | 27 | 30 | 40 | 2100*1485*2350 | 2500 |
| PC -820SF | 820*500 | 550-700 | 4 | 24 | 30 | 40 | 2100*1500*2300 | 2600 |
| PC-900SF | 900*700 | 800-1000 | 4 | 9 | 45 | 60 | 2600*1850*2500 | 4000 |
